The-vampire-4sa
The legendary Vampire 4SA d:-)
FPGA: Altera Cyclone V
CPU: Apollo 68080 Core
Equivalent to 1000MHz 68030 / 500MHz 68040 / 250MHz 68060 1)
Memory: 512 MB DDR3 RAM
Chipset: SAGA Core
12 MB of fast ChipRAM
Video:
Modes up to 1280×720@60Hz, 1920×1080@24Hz
Color depths of 8, 15⁄16, 24, 32 bits per pixel
Hardware‐accelerated video playback
SAGA Native Graphics (AGA with enhanced features and performance)
Audio: 16‐bit 56 kHz sampling rate, 24‐bit mixing, 16 channels, panning
Networking: 100BASE‐TX Fast Ethernet
Internal Ports:
44‐pin Fast IDE Interface
Up to 18 MB/s data transfer speed 2)
JTAG Socket
2 x SPI‐capable Expansion Ports
I2S‐capable Expansion Port
I2C
68k Bus Expansion
External Ports:
Digital Video/Audio Out
MicroSD Card
2 x USB‑A
RJ45 Ethernet
2 x DB‑9
Mini‑B USB (board power)
